Concentric venting uses one pipe within a pipe; two-pipe venting uses two separate runs, and the right choice depends on wall space and layout.
Tell us what you need—we’ll call you back fast.
Quick answer
Concentric venting uses a single pipe-within-a-pipe design, where combustion exhaust flows out through the inner pipe while outdoor combustion air is drawn in through the surrounding outer pipe, all through one wall penetration. Two-pipe venting uses two entirely separate pipes, one dedicated to exhaust and one to intake, which can be routed independently and sometimes through different walls entirely. Both approaches serve sealed-combustion, high-efficiency gas boilers and water heaters, and the right choice depends on the appliance's certification, the available wall space, and the specific layout of the mechanical room.
Need a licensed gas fitter for your hot water / boiler? Call CANRO at (604) 359-1081 — residential natural-gas heating and hot water across Metro Vancouver since 1999.
Concentric venting is built as two pipes sharing a single axis: a smaller exhaust pipe runs inside a larger intake pipe, and both terminate together at a single combined fitting on the exterior wall or roof. Exhaust flows out through the centre pipe while fresh combustion air is drawn in through the surrounding annular space. Because both functions run through one assembly, concentric venting requires only a single wall penetration, which simplifies the exterior appearance and reduces the number of holes needed through the building envelope.
Two-pipe venting, by contrast, uses two completely separate and independently routed pipes: one carries exhaust to its own termination point, and the other draws in outdoor combustion air at its own separate termination. The two pipes do not need to exit through the same wall, or even the same side of the house, giving significantly more flexibility in how the venting is routed through a building, at the cost of two separate wall penetrations rather than one.
Concentric systems are often the more straightforward and commonly used option when the boiler or water heater sits reasonably close to a suitable exterior wall, since the combined fitting keeps the installation visually tidy and the routing simple.
Two-pipe systems generally allow longer total vent runs and more routing flexibility, which matters in larger homes or where the mechanical room sits well away from a usable exterior wall.
| Factor | Concentric Venting | Two-Pipe Venting |
|---|---|---|
| Wall penetrations required | One combined penetration | Two separate penetrations |
| Routing flexibility | Less flexible; both pipes travel together | More flexible; pipes can be routed independently |
| Typical maximum vent length | Often shorter, per the appliance's certified tables | Often longer, per the appliance's certified tables |
| Exterior appearance | Single, tidy termination fitting | Two separate terminations, which may be more or less visible |
| Common use case | Mechanical room near an exterior wall | Mechanical room farther from an exterior wall or needing separated terminations |
Neither option is universally superior; the manufacturer's certified installation manual for the specific boiler or water heater model sets out exactly which configurations are approved and what length and elbow limits apply to each. A technician selects the configuration based on your specific appliance and home layout, not personal preference.
The appliance manufacturer's venting tables specify exact maximum lengths and equivalent lengths for elbows in both configurations, and these numbers differ by model and even by BTU input rating on the same model line. A technician measures the actual planned route, counts the necessary elbows, and checks the result against those certified tables before finalizing which venting style to use. Clearance requirements from windows, doors, soffits, property lines, and the ground or expected snow line also factor into where the termination point (or points) can go, which sometimes decides the configuration on its own.
Safety note
Both concentric and two-pipe venting must be installed exactly to the appliance manufacturer's certified specifications, since incorrect sizing, routing, or clearances can affect combustion safety and allow exhaust gases to re-enter the home. If you smell gas or suspect a venting problem, leave the home immediately and call FortisBC at 1-800-663-9911. Only a Technical Safety BC licensed gas fitter should design or install this venting.
Neither is universally better — the right choice depends on the specific appliance's certified venting tables, the distance and routing available to an exterior wall, and the mechanical room's layout. A technician selects the configuration based on these factors, not a general preference.
It is possible in many cases, but it typically requires new pipe runs and possibly a new wall penetration, so it is treated as a real modification project rather than a simple swap. This is usually only considered if the current configuration is causing a specific problem.
Usually two separate penetrations, yes, though they can sometimes be routed to different walls entirely depending on the home's layout and the technician's plan. Concentric venting, by contrast, uses just one combined penetration.
Manufacturers publish specific maximum vent lengths and equivalent lengths for elbows for each venting configuration, and if your planned route exceeds what concentric venting allows, two-pipe venting's typically longer allowances may be necessary. A technician calculates this against your appliance's certified tables.
Yes, both high-efficiency condensing boilers and condensing tankless or storage water heaters can use either concentric or two-pipe venting configurations, depending on the specific model's design and certification.
A Technical Safety BC licensed gas fitter determines this based on the appliance manufacturer's certified installation manual, the measured route to a suitable termination point, and your home's specific layout and clearance requirements.
